$2999-12999
$2999-12999
| Specifications | CA6150 CA6150B CA6150C | CA6250 CA6250B CA6250C | |
| Max. Swing over bed | 500mm | ||
| Max. Swing over carriage | 300mm | ||
| Max. swing in gap | -- | 720mm | |
| Effective gap length | -- | 210mm | |
| Max. length of work piece | 750mm/1000mm/1500mm/2000mm/2200mm/3000mm/4000mm | ||
| Width of bed | 400mm | ||
| Section of turning tool | 25x25mm | ||
| Spindle | Spindle speeds | 10-1400rpm/16-1400rpm（24steps） | |
| Hole through spindle | 52mm（80mm）[10mm] | ||
| Spindle taper | NO.6（MT6）（Φ90 1：20）[Φ113 1：20] | ||
| Feed | Number of feeds | 64（kinds）（for each） | |
| Range of metric threads（kinds） | （1-192mm）44kinds | ||
| Range of inch threads（kinds） | （2-24tpi）21kinds | ||
| Range of module threads（kinds） | 0.25-48(Moduie39kinds) | ||
| Range of pitch threads（kinds） | 1-96DP(37kinds） | ||
| Tailstock | Max. tail stock spindle travel | 150mm | |
| Tail stock spindle diameter | 75mm | ||
| Taper of tail stock spindle center hole | NO.5(MT5) | ||
| Main motor | 7.5KW(10HP) | ||
| Packing dimensions (L*W*Hmm) | Overall dimensions for750mm | 2550x1140x1750 | |
|
Overall dimensions for1000mm |
2700x1140x1750 | ||
| Overall dimensions for1500mm | 3200x1140x1750 | ||
| Overall dimensions for2000mm | 3700x1140x1750 | ||
| Overall dimensions for2200mm | 4030x1140x1750 | ||
| Overall dimensions for3000mm | 4850x1140x1750 | ||
| Overall dimensions for4000mm | 5800x1140x1750 | ||
| Weight (kg) | Length | G.W N.W. | |
| Weight for 750mm | 2170 2061 | ||
| Weight for 1000mm | 2260 2140 | ||
| Weight for 1500mm | 2420 2290 | ||
| Weight for 2000mm | 2790 2640 | ||
| Weight for 2200mm | 2940 2790 | ||
| Weight for 3000mm | 3450 3300 | ||
| Weight for 4000mm | 3750 3600 | ||
